The document introduces a new product from the Hisense brand, the HDP2908D. This product uses the Toshiba G2 chip and the HY158 high-definition decoding chip, which provides good image and sound quality processing technology at a significant price advantage. The product has various features, including automatic channel search, reception of all CATV additional channel programs, and timer on/off function. The product supports the global top-level high-definition format 1080P, and has user-friendly features such as free listening, time-shift viewing, noise reduction demonstration, and timer reminder.
This manual introduces the HDP2908D television, detailing its hardware architecture, key features such as automatic program storage, FM radio capability, and special functions like timer recall and magnetic calibration. It also presents the product’s external design and connector layout.
The document includes extensive service information: circuit schematics, repair case studies, power consumption data, and step‑by‑step instructions for using advanced functions such as the 2‑hour timer reminder, FM radio setup, and screen‑cleaning mode. Technical specifications and connector pin‑outs are listed for reference during maintenance. This manual is written in Chinese.
