This manual introduces the functions and usage methods of SWAN NC simulation software, mainly including software overview, operation interface, function introduction, SINUMERIK 802S/c operation and SINUMERIK 802D operation.
The SWAN NC Simulation Software, developed by Nanjing Swan Software Technology, offers a virtual CNC environment that mimics real machines such as FANUC, SINUMERIK, Mitsubishi and others. It is intended for educational use and low‑cost practical training on milling, lathe and machining centre operations.
The manual is organized into chapters covering a summary of the software, startup interfaces, toolbar setup, file management, and detailed operation procedures for various SINUMERIK models (802S/c, 802D, 810/840, 801, 802Se). It also includes programming guides for G‑codes, cycles, arithmetic parameters and subroutines, plus instructions for network login and teacher‑computer configuration.
| Supported CNC control systems | FANUC, SINUMERIK, Mitsubishi, GSK, HNK, KND, DASEN |
|---|---|
| Supported ISO code | ISO‑1056 G and M codes |
The software supports FANUC, SINUMERIK, Mitsubishi, GSK, HNK, KND and DASEN CNC systems.
It supports ISO‑1056 preparatory G‑codes, secondary M‑codes, system‑defined codes and canned cycles.
