This manual introduces the CPU-1233 module's features and characteristics, including product overview, jumper description, interface description, setup program, etc.
This manual provides the complete description of the Eurotech CPU-1233 PC/104 module, including safety instructions, hardware interfaces, configuration menus, and troubleshooting guidance. It also contains the electrical, environmental, and mechanical specifications required for proper integration.
The document is organized into sections covering product overview, jumper settings, interface layouts (ISA, USB, Ethernet, etc.), setup programs, virtual peripherals, watchdog timer, and detailed specifications. Safety and regulatory information such as WEEE and RoHS compliance are also included. This manual is written in Chinese.
