LM3S1133 microcontroller datasheet, introduces the features and characteristics of the product, including product features, target applications, advanced block diagram, functional overview, ARM Cortex-M3 processor core, memory mapping, interrupts, JTAG interface, etc.
This document is the official datasheet for the LM3S1133 microcontroller, detailing its architecture, core features, and peripheral modules. It includes a high‑level block diagram, processor core description, and an overview of the device’s capabilities such as GPIO, timers, ADC, UART, SSI, I2C, and PWM.
The later sections cover pin‑out diagrams, electrical and DC characteristics, packaging information, ordering details, and support contacts. Appendices provide command sets, flash loading procedures, and reference design kit information for developers. This manual is written in Chinese.
| Processor Core | ARM Cortex‑M3 |
|---|---|
| Flash Memory | Flash storage available |
| SRAM | SRAM memory present |
Ordering information is provided in section C.1, listing part numbers such as LM3S1133‑IQC50.
The maximum rated DC value is listed under the DC characteristics section, but the exact number is not shown in the extracted text.
