This datasheet provides information about the LM3S815 microcontroller, including its structure, features, functions, and usage.
The LM3S815 data sheet provides a complete description of the microcontroller, including its ARM Cortex‑M3 core, memory map, interrupt system and peripheral modules such as GPIO, timers, ADC, UART, I2C and PWM. It also contains detailed electrical characteristics, package information and ordering codes.
Additional sections cover the JTAG interface, system control registers, flash memory features, and contact information for technical support from both Luminary Micro and its Chinese distributor Guangzhou Zhouli. This manual is written in Chinese.
| Package | 48‑pin LQFP |
|---|---|
| Device ordering code | LM3S815‑IQN50 |
The data sheet is copyrighted in 2007.
Contact Luminary Micro support via email [email protected] or call +1‑512‑279‑8800.
Guangzhou Zhouli Microcontroller Development Co., Ltd. is the Chinese distributor.
