The Infiniium 8000 series oscilloscope is the first oscilloscope in the industry to simultaneously feature fast response deep storage technology, 3D information viewing capability, and advanced analysis capability. The four models of the product, including digital storage oscilloscopes (DSO) and mixed signal oscilloscopes (MSO), all support the latest generation MegaZoom patented technology. This technology combines the deepest and most responsive storage with the latest high-definition display technology, allowing for the long-term capture and observation of key technical information in complex waveforms.
The Infiniium 8000 series combines high‑performance mixed‑signal (MSO) and digital storage (DSO) oscilloscopes with up to 1 GHz bandwidth, 4 analog channels and 16 digital channels. It introduces the MegaZoom technology for fast deep‑memory capture and 256‑level color XGA display.
The manual describes trigger capabilities, remote access via LAN/GPIB, hardware options, and ordering information, providing guidance for setup, measurement, and advanced analysis. This manual is written in Chinese.
| Maximum Bandwidth | 1 GHz (DSO8104A, MSO8104A) |
|---|---|
| Analog Channels | 4 |
| Digital Channels (MSO models) | 16 |
| Sample Rate | 4 GSa/s |
The series offers up to 1 GHz bandwidth on the DSO8104A and MSO8104A models.
Each MSO model includes 16 digital channels.
Yes, it can be accessed via a web browser, LAN, or GPIB for remote control and data transfer.
It features a 1024 × 768 XGA color display with 256 brightness levels.
