This instruction manual is the user manual of car radio CZ109. It mainly introduces the function features, usage methods and precautions of the radio.
This manual explains safe usage, installation, and operation of the Clarion CZ/709 car audio receiver. It includes warnings, handling of the DCP unit, and instructions for CD, MP3, and WMA playback, as well as Bluetooth and AUX input usage.
Additional sections cover display settings, error messages, maintenance, and warranty information, with detailed technical specifications such as frequency response, power output, and dimensions. This manual is written in Japanese.
| Frequency response | 10Hz‑20kHz |
|---|---|
| Rated output | 20W×4 (80Hz‑80kHz, 1%) |
| Signal‑to‑Noise ratio | 80dB (1kHz) |
| Dynamic range | 85dB (1kHz) |
| Harmonic distortion | 0.01 % |
| Reception frequency (tuner) | 76.0 MHz‑80.0 MHz |
| Tuner sensitivity | 10 dBµV |
| Maximum file count | 578 files |
| Maximum folder count | 256 folders |
| Maximum filename length | 32 bytes |
| Supported sampling rates (MP3) | 32‑48‑44.1‑48 kHz (MPEG‑1), 16‑22.05‑24 kHz (MPEG‑2), 8‑11.025‑12 kHz (MPEG‑2.5) |
| Maximum output power (MP3/WMA) | 50W×4 |
| Impedance | 4 Ω (40‑80 Ω range) |
| Bass control | -14 dB (100 Hz) |
| Treble control | -14 dB (10 kHz) |
| Magnabase EX boost | +10 dB (50 Hz) |
| Power supply voltage | DC 14.4 V |
| Current consumption | 3.0 A (1 W) |
| Dimensions (W×H×D) | 178 mm × 50 mm × 175 mm |
| Weight | 1.1 kg |
