This is a product manual for a photoelectric distance sensor
This manual provides detailed instructions for installing, wiring, configuring and maintaining the ifm O1D100/O1D103 photoelectric distance sensor. It includes safety warnings, functional descriptions, menu navigation, parameter settings and troubleshooting guidance.
The document also contains technical specifications such as detection range, background suppression, output functions and dimensional drawings, helping users set up the sensor correctly for reliable operation. This manual is written in Japanese.
| Detection distance | 0.2–10 m |
|---|---|
| Background suppression range | 10–100 m |
| Display type | 4‑digit segment display |
| Analog output | Proportional to distance (OUT2) |
| Supply voltage | EN 50178, SELV, PELV compatible |
The sensor can detect distances from 0.2 m up to 10 m.
The sensor uses a Class 2 laser, so users must avoid looking directly at the beam and follow the warning labels.
Connect the sensor to a power source that complies with EN 50178, SELV or PELV standards.
