This manual introduces the basic operations of BenQ DC 5530 digital camera, including using, maintaining and troubleshooting.
This manual covers everything you need to know to get started with the BenQ DC C530 digital camera, including unpacking, battery installation, SD‑card handling, menu navigation, shooting modes, and connecting to a PC. Detailed sections explain each button, LCD indicators, and how to adjust settings such as ISO, white balance, and exposure.
Safety guidelines, storage recommendations, and a full specifications table are also included, along with troubleshooting tips for common issues like low battery, storage errors, and shutter problems. This manual is written in Chinese.
| Image sensor | CCD, 5 MP |
|---|---|
| Static image sizes (JPEG) | 2304×1728, 2048×1536, 1280×960, 640×480 |
| Video clip size | 320×240 at 30 fps (Motion JPEG AVI) |
| Recording media | 8 MB internal memory, SD card |
| Lens aperture (F‑no.) | 2.8 (wide) / 4.8 (tele) |
| Focal length | 5.4 mm–16.2 mm (35 mm equiv. 32–96 mm) |
| LCD display | 2.4‑inch TFT LCD |
| Power source | 2 AA batteries |
| Dimensions | ≈ 89.3 × 28.6 × 61.1 mm |
| Weight | ≈ 130 g (without battery and SD card) |
| ISO range | Auto, 64, 100, 200 |
| White balance modes | Auto, Daylight, Cloudy, Tungsten, Fluorescent |
| Exposure compensation | -2.0 EV to +2.0 EV (0.3 EV steps) |
Make sure the camera is turned off, open the battery cover, insert two AA batteries in the correct orientation, then close the cover.
Before using the camera for the first time, format the SD card using the camera’s format function.
Check that the battery has sufficient charge, confirm the camera is set to a shooting mode, and press the shutter button fully.
