The IBM Ethernet Switch S Series is a family of high-performance, intelligent, enterprise-class Ethernet switches that are optimized for delivering network convergence. These switches are designed to extend control from the network edge to the core to provide intelligent network services, including outstanding quality of service (QoS), predictable performance, advanced security, and comprehensive management and integrated network resiliency. The Ethernet Switch B08S and B16S use a common operating system and share interfaces and power modules to help you maximize operating costs and improve return on investment (ROI), thereby reducing total cost of ownership.
The IBM B08S and B16S Ethernet switches are high‑performance, modular devices designed for network convergence, offering line‑rate Gigabit Ethernet, PoE, QoS, and full L2/L3 routing capabilities. They share a common operating system and modular power, fan, and interface slots to reduce total cost of ownership.
Key features include IEEE 802.3af PoE (up to 15.4 W per port), extensive L2/L3 protocol support (STP, LACP, OSPF, BGP, RIP, etc.), robust security (SSHv2, SNMPv3, TACACS+, RADIUS), and optional IPv6 modules. The switches provide high availability with 1+1/N+1 power architectures and scalable port configurations. This manual is written in Chinese.
| Data Forwarding Capacity (B08S) | 348 Mpps |
|---|---|
| Switching Capacity (B08S) | 600 Gbps |
| 10/100/1000 MbE Ports | 24 ports |
| 10 GbE Ports | 2 ports |
The B16S provides four system power slots.
