PXI3002 is a high-speed data acquisition card that can be used in testing, measurement, and control applications to form data acquisition, waveform analysis, and processing systems. It has 2 channels for pulse signal acquisition and 2 channels for computer word signal acquisition, supporting acquisition and self-test modes.
The PXI3002 is a high‑speed data acquisition card based on the PXI standard, intended for test, measurement, and control applications such as manufacturing testing, industrial testing, and process monitoring. It supports two pulse‑signal acquisition channels and two computer‑word acquisition channels with self‑test capabilities.
The manual includes functional overviews, detailed component layout and connector pin‑outs, step‑by‑step connection methods for all signal types, and warranty information. Users are advised to avoid touching the front‑side IC chips to prevent static damage. This manual is written in Chinese.
| Pulse acquisition channels | 2 |
|---|---|
| Pulse self‑test channels | 1 |
| Pulse acquisition mode | Acquisition, Self‑test |
| Pulse self‑test frequency | 1 Hz ~ 20 MHz |
| Pulse feature code range | 00H ~ FFH |
| Computer‑word acquisition channels | 2 |
| Computer‑word self‑test channels | 1 |
| Computer‑word self‑test frequency | 1 Hz ~ 4.096 MHz |
| Pulse signal reference clock | 40 MHz |
| Computer‑word signal reference clock | 8.192 MHz |
The PXI3002 provides two pulse‑signal acquisition channels.
The self‑test frequency for pulse signals ranges from 1 Hz to 20 MHz.
Do not touch the IC chips on the front of the board to prevent static damage.
