This is a user manual, which mainly introduces the features and characteristics of the NOVO 7845GV product
The NOVO PC3120 and PC1200 are compact single‑board computers built around the AMD SC1200 chipset. They integrate a 266 MHz CPU, 128 MB of SDRAM, VGA, LAN, IDE, USB and other I/O interfaces on a small form factor board.
This manual provides an overview of the product, lists the main technical specifications, describes installation steps, external connector pin‑outs, and details BIOS configuration options for system setup and troubleshooting. This manual is written in Chinese.
| Dimensions (PC‑3120) | 153 mm × 102 mm |
|---|---|
| CPU Speed | 266 MHz |
| Chipset | AMD SC1200UFH |
| Expandable Memory Slot | SO‑DIMM (supports 66 MHz/100 MHz modules) |
| On‑board VGA | Integrated VGA, 2‑D graphics mode |
| LAN Controller | Realtek 8100C, 10/100 Mbps |
| IDE Interface | Two IDE channels (IDE HDD & CD‑ROM), ATA33, UDMA/100 |
| USB Ports | Three USB 1.0 ports |
It uses an integrated CPU running at 266 MHz.
A Realtek 8100C chip providing 10/100 Mbps Ethernet connectivity.
