This manual provides detailed instructions on how to use the BBT410S/BBT210S/BBT110S Bluetooth speaker system, including device connection, function settings, and maintenance.
This manual explains the features and components of the Yamaha BBT410S, BBT210S and BBT110S speaker systems, including woofers, tweeters, input jack and supplied accessories. It guides users on proper installation, safe handling, and maintenance to ensure optimal performance and longevity.
Key sections cover speaker specifications, connection procedures, amplifier requirements, tweeter level adjustment, safety precautions, and wiring diagrams. The document also includes tables of dimensions, power handling, impedance and weight for each model.
| Model | BBT410S |
|---|---|
| Woofer size | 25 cm |
| Number of woofers | 4 |
| Number of tweeters | 1 |
| Power handling | 250 W RMS |
| Dimensions (WxHxD) | 596 x 640 x 483 mm |
Use the supplied speaker cable or a standard monaural phone plug, ensure all devices are switched OFF, and connect the INPUT jack on the rear panel to the speaker output jack on the amplifier.
The speakers are rated for 250 W RMS power handling and 4 Ω impedance, so the amplifier’s output must match these specifications.
Turn the TWEETER LEVEL control knob on the rear panel of the speaker to set the output level of the tweeter.
