This manual explains the type of lamps that can be connected to the MG32/14 FX and MG24/14 FX mixing consoles and how to connect them correctly.
This manual provides safety warnings, lamp connection guidelines, wiring instructions, and FCC compliance information for the Yamaha MG32/14FX and MG24/14FX mixing consoles. It also lists recommended lamp types and explains how to avoid electric shock or fire hazards.
The document includes detailed plug wiring colour codes for U.K. installations, FCC notices for the United States, and contact information for Yamaha distributors worldwide. Service should be performed only by qualified personnel. This manual is written in Spanish.
| Lamp voltage | 12 V AC/DC |
|---|
No. The unit contains no user‑serviceable parts and must be serviced by qualified personnel.
Connect the green‑and‑yellow wire to the earth terminal (E), the blue wire to neutral (N), and the brown wire to live (L).
