IRCON Modline 5 infrared thermometers are compact, NEMA‑4 rated sensors with smart features for harsh industrial processes.
The Modline 5 series provides non‑contact temperature measurement for a wide range of high‑temperature industrial applications. Sensors are housed in a sealed stainless‑steel NEMA 4 (IP65) enclosure, are less than 5.7 cm in diameter, and offer options such as Dirty Window Detector, laser sighting, and built‑in calibration.
Configuration is flexible: analog 0–20 mA output, bi‑directional RS‑485 digital I/O, and optional POI power boxes or terminal strip plates. A PC‑based Modview Configuration Software and a 10‑inch Multi‑Sensor Interface enable remote setup, monitoring, and data logging for up to twelve sensors.
| Spectral Range | 0.85–1.1µm |
|---|---|
| Accuracy @ 25ºC | 0.3% of reading, +1ºC |
| Response Time | 6.6 ms |
| Emissivity Range | 0.100–1.000 |
| Environmental Rating | NEMA 4 (IP65) |
| Power Requirements | 24 VDC ±5%, 8 W max |
| Temperature Range | 500 °C to 3000 °C |
All Modline 5 sensors are housed in a sealed stainless‑steel NEMA 4 (IP65) enclosure.
The DWD automatically detects window build‑up and sends an alarm output to notify the user.
Modview Configuration Software is supplied with every sensor for PC‑based setup, parameter adjustment, and data logging.
