Modline 5 Infrared Thermometers are reliable non-contact temperature measurement devices. These infrared thermometers are designed for a wide range of industrial applications, and they always deliver accurate, repeatable, and reliable measurements, even under harsh environmental conditions.
The document presents technical information for the Modline 5 series of infrared thermometers designed for industrial applications. It highlights key features such as high precision, reliability in harsh environments, and intelligent functions like automatic sensor self-monitoring and internal self-calibration.
Specific models are detailed with their respective temperature ranges and spectral wavelengths: Series 52 (500-3000°C), Series 56 (600-3000°C dual detector), Series 5R (250-2000°C), and Series 5G (50-800°C). The text also describes sensor options including the patented Dirty Window Detection system, laser spot marking, and calibration transfer standards. This manual is written in German.
| Wavelength (Series 52) | 0,85–1,1 µm |
|---|---|
| Wavelength (Series 56) | 0,75–1,05 µm und 1,0–1,1 µm |
| Wavelength (Series 5R) | 1,6 µm |
| Wavelength (Series 5G) | 2,3 - 2,6 µm |
Yes, it features a patented DWD-System (Dirty Window Detector) that permanently monitors the optics for contamination.
The robust stainless steel housing has a diameter of only 5.7 cm.
The sealed stainless steel housing possesses the protection class IP65.
