Rosemount 1151 series pressure transmitters have the characteristics of small, sturdy, easy to install structure, adjustable damping, easy to maintain and upgrade, and are widely used.
The Rosemount 1151 series pressure transmitters are compact, rugged devices used for differential, gauge, absolute, vacuum, level and density measurements in industrial automation. They support smart, analog or low‑power output options and a wide pressure range from 0‑0.5 inH₂O up to 6000 psig.
This manual covers transmitter configuration with a HART handheld, testing procedures, specific setting adjustments, communication modes, power requirements, display options, process‑interface selections, calibration, and performance specifications such as accuracy, temperature limits and static‑pressure ratings. This manual is written in Chinese.
| Pressure range | 0‑0.5 inH₂O to 6000 psig |
|---|---|
| Output options | Smart, analog, low‑power (codes S, E, G, J, L, M) |
| LCD display temperature limit | -4 °F to 158 °F |
It can be configured with a HART handheld communicator to set zero, range, output type, damping, engineering units and other parameters.
The LCD display operates from –4 °F to 158 °F (‑20 °C to 70 °C).
