ASUS P5K SE User Manual

Asus P5K SE motherboard user manual, introduces the features and characteristics of the motherboard, hardware device information, power on, BIOS program settings and other content

Brand: ASUS
Category: Other Computer Accessories
Document type: User Manual
Language: Japanese
Pages: 136
File format: PDF
File size: 2.6 MB
Published: 21 September, 2011
Updated: 30 September, 2023
Model: P5K
MD5 checksum: B7EA833EC54D2FA359AC67794577822F
PDF: ASUS P5K SE User Manual PDF

About this manual

This manual covers safety precautions, hardware installation steps, and system configuration for the ASUS P5K SE motherboard. It includes detailed safety information, component identification, and guidelines for handling the board before power is applied.

The document also explains BIOS setup, jumper configuration, PCI‑Express slot usage, SATA and IDE connections, power‑management options, and utility tools such as ASUS EZ Flash 2. Each chapter provides step‑by‑step instructions for assembling, configuring, and troubleshooting the motherboard. This manual is written in Japanese.

What's inside

Safety Information
Product Introduction
Hardware Information
Power Management
BIOS Setup
Jumper Configuration
PCI Express Slots
SATA and IDE Connections
Boot Menu
Tools Menu

Specifications

SATA ports	1‑4
IDE configuration	available
PCI Express x1 slot	present
PCI Express x16 slot	present
Suspend Mode (default)	Auto

Frequently asked questions

What safety precautions should be taken before installing the motherboard?

Before installing the board, disconnect all power sources, handle components carefully, and ensure all connectors are properly seated to avoid damage.

How can I update the BIOS on the P5K SE motherboard?

Use the ASUS EZ Flash 2 utility available in the BIOS menu to load and flash a new BIOS image.

Which PCI‑Express slots are available on the board?

The motherboard provides one PCI‑Express x1 slot and one PCI‑Express x16 slot.
