This manual introduces the use of TEFEN MixRite TF5 Fertilizer and Chemicals Injector.
The TEFEN MixRite TF5 is a high-quality fertilizer and chemicals injector designed to be fitted on water lines. It operates by using the flow of water passing through it to activate a pumping mechanism that injects liquid additives into the line in relative quantities. The device features a technical working range for water flow between 2 and 25 m³/Hr (9 – 110 GPM) and supports water pressures from 1 to 8 bar.
| Flow rate range | 2 and 25 m³/Hr (9 – 110 GPM) |
|---|---|
| Water pressure range | 1 and 8 bar (14.7 and 120 PSI) |
| Temperature range | Not less than 4°C and not more than 40°C |
The maximum deviation for the injection rate is +/- 10%.
The injector operates with a water flow rate between 2 and 25 m³/Hr.
The device requires a water pressure between 1 and 8 bar.
The fertilizer flow can be adjusted up to 5.5% relative to the water flow.
