The ROTAMASS series is a family of high‑accuracy flow meters that can measure liquids, gases, and multiphase fluids. The manual describes the measurement principle, available models, and the range of applications, including hazardous‑area installations.
It provides detailed performance specifications, mechanical characteristics, electrical connection diagrams, safety guidelines, and calibration procedures. The document also lists compatible standards (ATEX, IECEx, GOST, etc.) and environmental limits such as temperature and pressure ranges. This manual is written in Japanese.
| Operating Temperature Range | -200 °C to +350 °C |
|---|---|
| Maximum Working Pressure | 100 bar (depending on model) |
| Power Supply (AC) | 90‑264 V AC, 47‑63 Hz |
| Maximum Power Consumption | 25 VA / 10 W |
It can operate from –200 °C up to +350 °C.
The maximum pressure rating varies by model, up to 100 bar for the highest‑rated versions.
