The document presents the key parameters of the LME63V, a high‑frequency switching device. It lists the maximum and minimum lamp voltages, current limits, power ratings and other electrical characteristics.
Additional data such as capacitance values, maximum switching frequency and secondary voltage limits are also included, giving designers the necessary information for circuit integration. This manual is written in Japanese.
| Maximum lamp voltage | 6.9 V |
|---|---|
| Minimum lamp voltage | 5.7 V |
| Maximum lamp current | 20 mA |
| Maximum power dissipation | 1.8 W |
| Maximum secondary power dissipation | 0.55 W |
| Maximum secondary voltage | 150 V |
| Maximum primary voltage | 200 V |
| Capacitance | 2.35 pF |
| Maximum switching frequency | 1 MHz |
The maximum lamp voltage is 6.9 V.
The maximum lamp current is 20 mA.
The component can dissipate up to 1.8 W.
The maximum switching frequency is 1 MHz.
