The F85RN is a LED driver module designed for operation from a DC input of 12 V to 24 V with a ripple tolerance of 10 %. It provides selectable NPN or PNP output configurations and supports LED loads up to 770 mW (ECO) or 600 mW (ECORE) at 660 nm wavelength. The device includes timing functions such as ON/OFF delay and timer control.
The driver is rated for operation in temperatures from –25 °C to +55 °C, humidity up to 85 %RH, and an IP40 protection level. Mechanical dimensions and mounting details are provided for integration into various lighting applications. This manual is written in Chinese.
| Input Voltage | DC 12~24 V |
|---|---|
| Input Ripple | 10 % |
| LED Wavelength | 660 nm |
The driver accepts a DC input voltage from 12 V to 24 V.
