This manual outlines safety information, electrical symbols, and proper handling procedures for the ZX Automotive Tester. It includes warnings about electric shock, battery replacement, and fuse replacement, as well as guidance on using test leads and accessories.
The document also details the instrument's general and technical specifications, such as display resolution, measurement methods, temperature ranges, power supply, dimensions, and weight. Operating instructions cover voltage and current measurement, function selection, and maintenance tasks.
| Maximum Display | 1999 counts (3 1/2 digits) |
|---|---|
| Indication Method | LCD display |
| Measuring Method | Dual‑slope integration A/D converter system |
| Operating Temperature | -40°C ~ 40°C (32°F~104°F) |
| Power Supply | One 9‑V battery (NEDA1604, 6F22) |
| Dimensions | 200 × 97 × 48 mm |
| Weight | 495 g (including one 9V battery) |
| Input Impedance | 10 MΩ for all ranges |
Replace the battery as soon as the low‑battery indicator appears on the LCD.
Use a 250 mA/250 V fast‑blown fuse.
The input impedance is 10 MΩ for all measurement ranges.
The meter is designed for Category I (CATI 600 V) measurements.
