This manual begins with safety warnings, grounding requirements, and cautions for use near water, children, and high sound levels. It also outlines proper handling of the power cord, fuse specifications, and when to seek qualified service.
The document describes the front and rear panel controls, including LCD display, master knobs for music, mic, sub‑woofer, and effect parameters, as well as RS‑232, video inputs, and wireless remote operation. Detailed operating instructions cover music, sub‑woofer, mic, and effect adjustments, and a full specification table lists electrical and audio performance data.
| Power supply | AC 90‑250V/50Hz |
|---|---|
| Fuse rating | T1AL/250VAC |
| Dimensions | 45 × 482 × 170 mm |
| Music THD | 0.01 % (20 Hz‑20 kHz) |
| Music frequency response | 20 Hz‑20 kHz ±0.5 dB |
The unit requires a fuse rated 90 V‑250 VAC, type T1AL/250 VAC.
The wireless remote provides simple parameter setup for volume, effect, and tone controls, allowing remote adjustment of music, mic, and sub‑woofer settings.
