This document is an installation and user manual for TEMP880 temperature programmable controller. The manual includes installation instructions and user manual. The temperature programmable controller is available in color type and mono type models.
The document serves as an instruction manual for the SAMWONTECH TEMP880 (and TEMP850) Temperature Programmable Controller. It details safety precautions, installation requirements including environmental conditions and panel mounting, and wiring procedures.
The guide provides comprehensive instructions on operating the device, covering various screen modes such as Setup, Input Setting, Operation, Pattern Setting, and System Settings. It also includes a parameter setting table and a communication manual for integration with other systems.
| Operating Temperature (Storage) | -25~70C |
|---|---|
| Operating Humidity | 5~95%RH (dew free) |
| Power Supply Voltage | 100~240VAC |
| Warranty Period | One year from purchase |
The fuse SR-5 has a semi-permanent life, the backlight lasts 10,000 to 15,000 hours, and the relay is rated for less than 300,000 ON/OFF cycles.
The product comes with a one-year warranty from the date of purchase for damages occurring under normal circumstances.
