SIMOTICS 1LE0 series motors are general-purpose fully enclosed self-ventilated three-phase asynchronous motors suitable for continuous duty and variable frequency speed control applications. They feature frame materials of grey cast iron or aluminum, standard color of stone grey, rated power output of 0.55kW~315kW, motors with efficiency grade 2 or 3 and IE2 or IE3 efficiency class.
The Siemens SIMOTICS 1LE0 series consists of general-purpose, totally enclosed fan-cooled (TEFC) three-phase asynchronous motors with an IP55 protection rating. These motors are designed and manufactured in accordance with ISO, IEC, and GB standards for constant or adjustable speed applications with continuous duty operation (S1). The series features optimized compact construction and is available in frame sizes from 80 to 355.
| Rated power output | 0.55kW~315kW at 50Hz |
|---|---|
| Protection degree | IP55 |
| Insulation temperature class | 155 (F) |
| Standard mounting types | IM B3, IM B5, IM B35 |
The standard color is stone grey (RAL 7030).
The altitude shall not exceed 1000m above sea-level.
Options include PTC, PT100, and KTY84-130 for winding protection.
