This document introduces a tough fiber optic product that is not easily broken and can be bent. It can be used in a wide temperature range. The product uses new materials and has high-precision detection and stable light output. Using this product can reduce installation risks, save selection time and costs.
This document provides user instructions for the Panasonic FX-500/551 series digital fiber optic sensors. It details various product types such as toughened fiber (FT-R/FD-R) with high bend resistance and built-in lens models (FT/FD) designed for narrow spaces. The guide explains how to select appropriate models based on detection distance, output type (NPN/PNP), and application requirements like analog or digital switching. This manual is written in Chinese.
| Power Supply Voltage | 12V DC ~ 24V DC +10-15% |
|---|---|
| Operating Temperature | -10℃～＋55℃ |
| Reaction Time (H-SP) | 25μs or less |
| Analog Output Current | 4mA～20mA |
The minimum bending radius is R1mm.
Yes, it can switch to an ECO mode to reduce power consumption.
