This product complies with the requirements of European Directive 89/336/EEC.
The BOSS FS-6 is a dual foot switch that combines the functions of the FS-SL (latch type) and FS-5U (momentary type). It allows users to control devices connected to TRS 1/4" phone jacks, with both switches configurable as either latch or momentary types. The unit can be connected to other BOSS or Roland devices compatible with the FS-5L or FS-5U.
| Power Supply | DC 9 V: Dry battery/9 V 6F22 (carbon), 6LR61 (alkaline) |
|---|---|
| Expected battery life (Carbon) | 70 hours |
| Expected battery life (Alkaline) | 100 hours |
| Current Draw | 8 mA (max.) |
| Dimensions | 188 (W) x91 (D) x 43 (H) mm |
| Weight | 470 g / 1b 1 oz (including battery) |
Open the battery cover, remove the old battery and snap cord, connect the snap cord to the new battery observing correct polarity, place the battery inside, and close the cover until it clicks.
It indicates that the battery is near exhaustion and should be replaced immediately.
Yes, the FS-6 can be connected to another FS-6, a FS-5U/SL, or an AB-2.
