This document provides safety instructions for using the unit, including not opening or modifying the unit, not attempting to repair or replace parts, and not exposing the unit to extreme temperatures, dampness, rain, dust, or high vibration levels.
The BOSS FV-500L is a low-impedance stereo volume pedal designed for connecting to effects processors, keyboards, and other devices with low-impedance outputs. It features a dedicated TUNER OUT jack to allow tuning without changing cable connections and an EXP jack for use as an expression pedal with compatible instruments. The unit includes a MINIMUM VOLUME knob to set the lowest volume level and a PEDAL FEEL adjustment screw to customize the resistance of the pedal mechanism.
| Control | Main volume (pedal) x 1, MINIMUM VOLUME knob x 1 |
|---|---|
| Connectors | INPUT jack x 2, OUTPUT jack x 2, TUNER OUT jack x 1, EXP jack x 1 |
| Dimensions (Max height) | 110 (W) x 289 (D) x 120 (H) mm |
| Weight | 1.6 kg/3 lbs 9 oz |
Rotate the PEDAL FEEL adjustment screw on the bottom panel; turning it left gives a lighter feel and turning it right gives a heavier feel.
Yes, with an optional connection cable (stereo 1/4" phone plugs at both ends), it can be used as an expression pedal.
The TUNER OUT jack lets you tune the instrument without having to change your cable connections or hear sound from the amplifier.
