AV-M8 Mic Input Module User Guide, introduces the module's features and characteristics, usage methods, installation methods, etc.
This document is the user guide for the Aviom AV-M8S Mic Input Module, part of the Pro16 and Pro64 series systems. It provides instructions on labeling channels, connecting audio sources (balanced and unbalanced), and setting gain levels. The guide also details the module's front and rear panel components, including inputs, switches, and LEDs.
| Operating Temperature | 10°C to 50°C (50°F to 122°F) |
|---|---|
| Warranty Period | one year |
No, there are no on/off power switches included in the system; the external power supply should be used to control power.
No, there are no user serviceable parts inside; servicing must be referred to qualified personnel.
