Operation instructions for Digital Triax Repeater AJ-. It provides safety information and operating guidelines for the product, including precautions and usage recommendations.
This manual provides operation instructions for the Panasonic AJ Digital Triax Repeater. The device is designed to extend digital triax cables by returning main system SDI signals to their default value, re-clocking them, and replaying them in waveform. It also amplifies return system RF signals to be nearly equivalent to the base station output. The document includes safety warnings, connection precautions, and technical specifications.
| Dimensions (W x H x D) | 125.5 x 90 x 225.5 mm |
|---|---|
| Weight | 2.5 kg |
| Allowable operating temperature | 0°C to 40°C |
| Allowable storage temperature | -20°C to +55°C |
| Max. number of repeaters (external power) | 3 |
| Max. number of repeaters (base station power only) | 1 |
| S/N deterioration per repeater | 3 dB (typ.) |
| BS input | 100 V DC, 850 mA max. |
| Power consumption | 7 W |
Up to three repeaters can be used when the camera adapter is connected to an external power source.
The allowable operating temperature is 0 °C to 40 °C.
