This document is a product bulletin from the Optoelectronics Division of TRW Electronic Components Group, dated January 1985. It covers GaAs Plastic Infrared Emitting Diodes of types OP161SL, OP161SLD, OP161SLC, OP161SLB, and OP161SLA.
The document provides mechanical dimensions, absolute maximum ratings, features such as low cost and plastic miniature end-locking T-1 packages, and notes on mounting. It also details electrical characteristics including radiant power output, forward voltage, and reverse current at 25°C.
| Storage and Operating Temperature Range | -40°C to +100°C |
|---|---|
| Lead Spacing | 0.100 inch (2.54 mm) |
