This is a very compact, lightweight 12V DC power supply that uses a 22kHz high frequency switching operation, outputs 7 amps continuous current, measures only 3.9 inches x 2.75 inches x 2.5 inches, and weighs only 7.2 ounces.
The DuraTrax DTXP4300 is a compact switching power supply designed to deliver 12V DC output at up to 7 amps. It features a high-frequency 22kHz design that eliminates the need for a heavy transformer, resulting in a lightweight unit measuring only 5.38" x 2.25" x 4.0" and weighing 7.2 oz. The device includes built-in thermal protection with an auto-reset feature and overload protection to ensure safe operation.
| Input Voltage | 110V AC, 60Hz, 1.5A |
|---|---|
| Output | 12V DC, 7A |
| Switching Frequency | 22kHz |
| Case Size | 5.38" x 2.25" x 4.0" |
| Weight | 7.2 oz. |
The output voltage can vary between 11-14V DC due to AC input line tolerance.
You must disconnect the supply from AC input and wait 15 seconds before reconnecting.
