This document lists detailed specifications of Sensaphone M1500 system, including memory, input, output, communication interface, size and weight, power requirements, battery backup, enclosure, operating environment, real-time clock, data logger, local indicators and system integrity
The Sensaphone ISACC is a remote monitoring system that combines monitoring, communications, and control capabilities into a single sophisticated system. It monitors up to 16 digital or analog inputs and provides alerts via voice, data, pager, or local alarm. The system features a built-in C language interpreter for advanced programming and includes a data logger that stores 512 events on board.
| Inputs | 16 User-definable digital or analog inputs |
|---|---|
| Outputs | 8 digital TTL cutputs and 4 analog outputs |
| Memory | 96K EPROM and 64K RAM |
| Data Logger Storage | Stores 512 events on board |
| Backup Battery | 10-14 hour Gel Cell |
| Power Consumption | 20 Watts |
| Operating Temperature | 32°-120°F |
ISACC can dial up to 8 phone numbers to alert key personnel.
No, it has a built-in C language interpreter and requires no additional software.
It supports dry contact, pulse count, 4-20 mA, 0-5 Volt, and Thermistor inputs.
