ST AN1695 Application note handbook

This application note describes the TSM108 Evaluation Board. The board can be used for different converter configurations, and is suitable for 12V to 6V DC/DC converters

Brand: STMicroelectronics
Category: Other Electronics
Document type: Application Note
Language: English
Pages: 5
File format: PDF
File size: 1.9 MB
Published: 06 August, 2012
Updated: 30 September, 2023
Model: TSM108
MD5 checksum: 8A03C02A0F3F8C88D28F289CB54D3125
PDF: ST AN1695 Application note handbook PDF

About this manual

The document details the TSM108 evaluation board, which features a step-down controller capable of constant voltage and constant current regulation. It is specifically designed to allow different converter configurations with various options for power semiconductor footprints on the PCB.

What's inside

Introduction
TSM108 typical application
Performances
Evaluation board description
Power semiconductors options

Specifications

Input voltage	12V
Output voltage	6V
Maximum output current	800mA
Efficiency range	84% to 90%

Frequently asked questions

What is the typical application for the TSM108?

The TSM108 is especially suited for cigarette lighter accessories.

What power semiconductor packages are available on the evaluation board?

The board supports TO220, D2PAK, TO92, and SO8 packages for the power switch and diode.
