Panasonic TH-152UX1 Plasma Display Operating Instructions

This document is the user manual for the TH-152UX1 high-definition plasma display. It provides guidance on safety, connections, and operation.

Brand: Panasonic
Category: Television
Document type: User Manual
Language: English
Pages: 24
File format: PDF
File size: 774 KB
Published: 03 August, 2012
Updated: 29 September, 2023
Model: TH-152UX1
MD5 checksum: 41643C0DB975A9B978F4CBA8D60C01FD
PDF: Panasonic TH-152UX1 Plasma Display Operating Instructions PDF

About this manual

This document provides operating instructions for the Panasonic TH-152UX1 Professional Flat Panel Display. It includes important safety notices regarding electric shock and fire hazards, as well as setup precautions such as ventilation requirements and proper mounting.

The guide details how to connect the display using various terminal boards (HD-SDI, DVI-D), power on/off procedures, and basic control operations. It also explains how to use the On-Screen Menu Displays and lists technical specifications for the unit.

What's inside

Important Safety Instructions
FCC STATEMENT
Safety Precautions
Accessories
Connections
Power On / Off
Selecting the input signal
Basic Controls
On-Screen Menu Displays
Specifications

Specifications

Product Type	High Definition Plasma Display
Voltage Range	200 - 240 V AC, 50/60 Hz

Frequently asked questions

What should I do if smoke or an abnormal odor comes from the display?

Immediately turn off the breaker and contact your local Panasonic dealer.

Can I place containers with water above the set?

No, do not place containers with water (flower vase, cups, cosmetics, etc.) above the set.
