This manual describes the features and usage of the ADSP-BF561 EZ-KIT Lite evaluation system, including the system's hardware configuration and usage instructions, as well as software downloading, compiling, and running instructions. This manual is aimed at engineers who are developing Blackfin applications using the ADSP-BF561 EZ-KIT Lite evaluation system.
This manual describes the ADSP-BF561 EZ-KIT Lite evaluation system, designed for use with the VisualDSP++ development environment to test Blackfin processor capabilities. The document covers the system architecture, including the ADSP-BF561 processor, SDRAM, and Flash memory, as well as various interfaces such as audio, video, and expansion ports.
| Processor | Analog Devices ADSP-BF561 |
|---|---|
| Clock Frequency | 30 MHz |
| SDRAM Capacity | 64 MB |
| Flash Memory | 8 MB |
| Audio Codec | AD1836A |
| Video Decoder | ADV7183A |
| Video Encoder | ADV7179 |
| Warranty Period | one year |
The manual is intended for users who want to test the capabilities of the ADSP-BF561 Blackfin processors using the VisualDSP++ development environment.
The EZ-KIT Lite is a licensed product that offers an unrestricted evaluation license for the first 90 days.
Yes, the board holds 8 MB of flash memory that can be used to store user-specific boot code, allowing the board to run as a stand-alone unit.
