BB119 is a variable capacitance diode product produced by Philips Semiconductors, packaged in SOD27 (DO-35), and applied to automatic frequency control.
This document is a product specification datasheet for the Philips BB119, a discrete semiconductor component designed as a variable capacitance diode. It features a hermetically sealed leaded glass SOD27 (DO-35) package and is intended for applications such as automatic frequency control.
The datasheet provides comprehensive technical data including limiting values for voltage, current, and temperature, as well as electrical characteristics like reverse current, series resistance, and capacitance at specific frequencies. It also includes graphical data illustrating the relationship between capacitance and reverse voltage, along with package outline dimensions.
| Continuous reverse voltage | -15 V |
|---|---|
| Continuous forward current | -200 mA |
| Storage temperature range | -55 to +150 °C |
| Operating junction temperature | -150 °C |
| Capacitance at 4V DC | 20 to 25 pF |
| Capacitance at 10V DC | -17 to - pF |
The device is intended for use in automatic frequency control applications.
It uses a hermetically sealed leaded glass SOD27 (DO-35) package.
The maximum reverse current under these conditions is 2 µA.
