FSQ500N is a single-chip 700V SenseFET power switch from Fairchild Semiconductor Corporation, which features a precise fixed operating frequency, low power consumption, soft-start, under-voltage lockout, overload protection, etc. It is suitable for STB, DSL, home appliances and other applications.
The FSQ500N is a single-chip 700V SenseFET power switch that combines a current-mode Pulse Width Modulator (PWM) with a SenseFET. It is specifically designed for low-cost, small set-top boxes, DSL, and home appliance auxiliary power supplies. The device eliminates the need for an auxiliary bias winding by integrating a high-voltage regulator.
| Switching Frequency | 130 kHz |
|---|---|
| No-Load Consumption | 250mW |
| Package Type | 8-Lead MDIP |
The device is designed for STB and DSL power supplies, as well as home appliance and IH cooker auxiliary power supplies.
No, the device eliminates the need for an auxiliary bias winding and associated external components.
