This document provides technical specifications and functional descriptions for the HL Hydraulik model R2-016-17-024G-B-KV3. It is a 2/5-way solenoid-operated directional control valve designed for hydraulic applications, featuring a stainless steel body suitable for high-pressure environments up to 250 bar.
The datasheet details the electrical requirements, including compatibility with various DC voltages (16V, 24V, 48V) and AC mains frequencies. It also outlines dimensional data, connection types such as SAE flanges and G threads, and specific configuration codes for different nozzle sizes and mounting positions. This manual is written in German.
| Operating Pressure | 250 bar |
|---|---|
| Body Material | Stainless Steel (Edelstahl) |
| Valve Type | 2/5-way Directional Valve |
| Electrical Supply (AC) | 220V/50Hz |
The valve has a rated operating pressure of 250 bar.
