The KMT32B is a magnetic field sensor based on the anisotropic magnetoresistance effect. The sensor contains two parallel supplied Wheatstone bridges, which enclose a sensitive angle of 45 degrees. A rotating magnetic field in the surface parallel to the chip (x-y plane) will deliver two independent sinusoidal output signals, one following a cos(2α) law.
The KMT32B is a magnetic angle sensor based on the anisotropic magnetoresistance effect. It contains two parallel Wheatstone bridges that provide sinusoidal outputs for angles up to 45°, suitable for high‑precision angle measurement under low magnetic field conditions.
The document lists target specifications such as supply voltage, resistance, signal amplitude, temperature coefficients, and pin assignments, along with legal disclaimer and ordering information.
| Supply voltage Vcc (typical) | 5‑8.5 V |
|---|---|
| Maximum supply voltage | 10 V |
| Bridge resistance (single bridge) | 3000 Ω (typical) |
| Signal amplitude ΔV/V (typical) | 20 mV/V |
| Offset voltage Voff (typical) | 0 mV/V |
| Angular inaccuracy Δα (typical) | 0.2° |
| Angular hysteresis ΔαH | 0.1° |
| Temperature coefficient of amplitude (TCSV) | -0.32 %/K (typical) |
The maximum supply voltage is 10 V.
Typical angular inaccuracy is 0.2 degrees.
Pin 5 (+Vo1) provides the positive output for bridge 1 (sin).
Typical signal amplitude is 20 mV/V.
