This document describes the features and characteristics of Hanna Instruments' Nickel High Range product, including technical specifications, functional description, and error warnings.
The Hanna Instruments HI 726Nickel High Range is a portable photometric meter designed to measure nickel concentration in samples. It utilizes a blue tint reaction between nickel and a specific reagent. The instrument features a liquid crystal display, a button for operation, and a cuvette holder for sample analysis. It operates using a single 1.5V AAA battery and includes auto-shutoff functionality.
| Range | 0.00 to 7.00 g/l |
|---|---|
| Resolution | 0.01 g/l |
| Accuracy | 0.10 g/l ±5 % of reading |
| Light Source | Light Emiting Diode @ 575 nm |
| Light Detector | Silicon Photocell |
| Method | Adaptation of the photometric method |
| Environment Temperature | 5 to 50 °C |
| Humidity | max 95% RH non-condensing |
| Battery Type | 1x 1.5V AAA |
| Auto-Shut off | After 10 minutes of non-use |
| Dimensions | 81.5 x 61 x 97.5 mm |
| Weight | 64 g |
The measurement range is from 0.00 to 7.00 g/l.
The instrument uses one 1.5V AAA battery.
The instrument automatically turns off after 10 minutes of non-use.
Interference may be caused by copper in the sample.
