This manual introduces the L-308BII exposure meter's operating methods, including safety precautions, part names, display, mode selection, light receiving method, measurement preparation, ambient light measurement, and flash measurement.
This manual provides operating instructions for the Sekonic L-308BIl Flashmate exposure meter. It details safety precautions regarding battery handling and electrical shock, as well as how to insert batteries and check their status. The device supports both incident and reflected light metering in ambient and flash modes.
| Light receiving element | Silicon photo diode |
|---|---|
| Ambient light measuring range | EV0 to EV19.9 (at 0.1 EV step) |
| Flash measuring range | F1.4 to F90+ 0.9 stop (at 0.1 AV step) |
| ISO display range | 3 to 8000 (at 1/3 SV step) |
| Shutter speed range | 60 sec to 1/8000 sec (at 1 TV step) |
| Battery type | A single type-AA battery (Alkaline or manganese), 1.5V |
| Operating temperature range | 0°C to 40°C |
Slide the lumisphere to the clicking position of 'a' for incident light or 'b' for reflected light.
The meter automatically turns off 4 minutes after your last operation to save battery capacity.
The 'b.c' display blinks and then disappears, indicating you should prepare a new battery.
