S direct plus is a direct insertion box that can be directly inserted into the PA system to convert instrument input signals to balanced output signals.
The Samson S direct plus is an active stereo direct insertion (DI) box designed for live sound and recording applications. It allows users to connect various audio signals, such as those from keyboards, drum machines, and guitars, into a mixer or recorder. The unit features stereo inputs and outputs, enabling the signal to be passed to a stage amplifier or monitor system without affecting the original sound, which is particularly useful for eliminating the need to microphone guitar amplifiers.
| Frequency Response | 10Hz - 20 kHz, -1 dB |
|---|---|
| Noise Level | -100 dBu |
| THD + N | 0.013% typ. |
| Input Impedance (GTR) | 1 Meg. Ohm |
| Input Impedance (SPK) | 10k Ohm |
| Max. Input Level GTR | +7 dBu |
| Max. Input Level SPK | +30 dBu |
| Dimensions | 5.6" W x 4" D x 2"H |
| Weight | 15 oz. |
The unit can operate on a single 9 Volt battery or standard 24-48 volt phantom power.
It automatically switches to phantom power when present on the XLR cable, disconnecting the 9 Volt battery.
They are used for passing the input signal through to a stage amplifier or monitor system.
