S amp is a portable four-channel headphone amplifier by Samson Audio. It provides a solution for headphone monitoring, either on stage or in the studio. You can use S amp to control the level balance between four sets of headphones. S amp uses high quality components and solid build construction, it can provide extraordinary power and superb audio fidelity. It is compatible with virtually all popular headphone models.
The Samson S-amp is a miniature headphone monitor system designed for use on stage or in the studio. It features four independent stereo headphone outputs with individual volume controls for each channel, allowing users to balance audio levels between four sets of headphones. The unit includes a stereo 1/4-inch input, a DC power input, and a rugged aluminum chassis.
| Input Impedance | 100K @ unbalanced |
|---|---|
| Input Connectors | Stereo 1/4" TRS phone |
| Outputs | (4) 1/4" Stereo |
| Output Impedance | 100 &2 each output |
| Max Gain | 20 dB/Channel |
| Power | 18 VDC adapter |
| Dimensions | 5.65" L x 4.13" W x 2" H |
| Weight | 16.5 oz., 419 gm. |
The S-amp provides maximum output power on each channel regardless of different headphone impedances.
The S-amp supports four channel stereo headphone amplifiers with individual volume control for each output.
The S-amp uses a stereo 1/4-inch TRS (TIP/RING/SLEEVE) connector to input the main stereo signal.
