This document describes the guaranteed specifications of the Cary Eclipse fluorescence spectrophotometer
The Agilent Cary Eclipse is a computer-controlled ratioing fluorescence spectrophotometer designed for measuring fluorescence, phosphorescence, chemiluminescence, and bioluminescence. It utilizes Czerny-Turner monochromators with a wavelength range of 190-1100 nm and features a full spectrum Xenon pulse lamp source.
| Wavelength range (Mechanical) | 190-1100 nm |
|---|---|
| Wavelength accuracy | +/-15 nm |
| Wavelength reproducibility | +/-0.2 nm |
| Sensitivity | >500:1 RMS |
| Instrument dimensions (WxDxH) | 608 x 644 x 271 mm |
| Sample compartment access | Front and top |
The instrument is centrally controlled by a PC with Windows 2000 or XP operating systems.
The maximum scan speed and rate are 24,000 nm/min (400 nm/sec).
The minimum gate time available for data collection in the lifetimes application is 1 ps.
