Agilent 2257 J&W Select PAH Column is a novel high selectivity stationary phase introduced by Agilent for accurate analysis of polycyclic aromatic hydrocarbons (PAH). The Select PAH is the first capillary column that provides a single solution for PAH analysis by separating all the isomers, thereby avoiding false positives and inaccurate results. Select PAH is the only product that provides easy, fast and accurate quantification of PAHs in environmental and food samples.
The Agilent 2257 J&W Select PAH Column is a novel capillary column designed to provide a single solution for the accurate analysis of polycyclic aromatic hydrocarbons (PAHs). It separates all PAH isomers, avoiding false positives and inaccurate results often associated with co-elution in mass spectrometry. This column offers high resolution, allowing for the easy quantification of 54 regulated PAHs in environmental and food samples.
| Maximum Programmable Temperature | 350 °C |
|---|---|
| Column Length (Part CP7461) | 15 m |
| Column ID (Part CP7461) | 0.15 mm |
| Column Length (Part CP7462) | 130 m |
| Column ID (Part CP7462) | 0.25 mm |
| Resolution (CHR/TP) Part CP7461 | 0.75 |
| Bleed (Part CP7461) | 0.6 pA |
| Resolution (CHR/TP) Part CP7462 | 0.80 |
| Bleed (Part CP7462) | 2.0 pA |
The column delivers fast analysis of 54 PAHs in less than 30 minutes.
The column delivers full separation of 16 EPA PAHs within 7 minutes.
The Select PAH has a maximum programmable temperature of 350 °C.
Yes, the crosslinked stationary phase makes the column rinseable for extended lifetime.
