The Varian TPS Turbo Pumping Systems are portable, fully integrated vacuum solutions available as light dry bench-top solutions for small and medium volumes, or high capacity, wide pumping speed range cart versions. The TPS-compact features the unique IDP-3 Dry Scroll Pump, which is the most compact and light scroll pump on the market. It has an innovative hermetic design with the motor and bearings outside the vacuum space, an integrated pump isolation valve, and cost-effective and easy tip-seal replacement. The TPS-compact / Mini-TASK AG81 has active full range combined gauge capability, providing pressure data from atmosphere to 5x10-9 mbar (7x10-9 Torr) with Pirani and Cold Cathode gauges. The pressure data is available on three independent channels: serial communication, analog output, and the gauge can be connected/disconnected from the TPS-compact / Mini-TASK during normal operation.
The Agilent TPS Turbo Pumping Systems family offers portable, fully integrated vacuum solutions ranging from light dry bench-top units to high-capacity cart versions. These systems are designed for small and medium volumes, providing wide pumping speed ranges and enhanced, reliable vacuum performance without oil contamination.
The product line includes the Mini-TASK AG81, a compact dry system with active gauge capability; the TPS-compact, featuring the unique IDP-3 dry scroll pump; and the TPS-mobile and TPS-bench models powered by Varian Turbomolecular pumps. All units support worldwide power configurations and include global technical support.
| Pumping Speed (N2) | 40 l/s |
|---|---|
| Turbo pump rotational speed | 80,000 rpm |
| Operating Ambient Temperature | 5 °C to 35 °C |
They are portable, fully integrated vacuum solutions available as light dry bench-top solutions or high capacity cart versions.
No, it is a dry system with no maintenance required and features a simple tip seal replacement.
It is well suited for Electron Microscopy, Mass Spectrometry, Semiconductor Manufacturing, and Industrial Applications.
