This guide introduces the features and characteristics of the GSR speakers.
This user guide provides instructions for setting up and connecting the M-Audio GSR series of active loudspeakers, including the GSR10, GSR12, and GSR18 models. It details speaker positioning options such as standing, floor wedge, flown, and mounted configurations, as well as AC power connections and audio input setups like microphone and daisy-chaining.
| Frequency Response (GSR10) | 72 Hz to 16 kHz |
|---|---|
| System Power Rating (GSR10) | 250 W continuous, 500 W peak |
| Frequency Response (GSR12) | 53 Hz to 20 kHz |
| System Power Rating (GSR12) | 300 W continuous, 600 W peak |
| Frequency Response (GSR18) | 45 Hz to 100 Hz |
| System Power Rating (GSR18) | 500 W continuous, 1000 W peak |
| Nominal Impedance | 8 Ohms |
| AC Input Voltage | 100–120 VAC ~ 60 Hz / 220–240 VAC ~ 50 Hz |
Yes, you can daisy-chain up to three total GSR speakers together per channel using the Thru output XLR jacks.
You should never daisy-chain more than three total GSR speakers together per channel.
The GSR10 has a system power rating of 250 W continuous.
The GSR18 subwoofer has a height of 25.6 inches.
