This document is the installation guide for VMware vFabric AppInsight, which provides information on system requirements, installation steps, and registering the vCenter adapter.
VMware vFabric AppInsight is a performance management product designed to monitor the availability, performance, and cost of applications deployed in hybrid clouds and dynamic virtual environments. It provides an at-a-glance health state by monitoring network-based metrics and code-level details across infrastructure and middleware layers.
The document outlines system requirements for ESX servers, including disk space, memory, and open ports (TCP 80, 8443, 1194, etc.). It provides step-by-step instructions for installing the AppInsight server virtual machine and network probes, registering the vCenter adapter, deploying code agents on supported application servers like Tomcat, JBoss, and TC Server, and configuring Cisco Nexus 1000V switches.
| ApplInsight Server virtual machine disk space | 50 GB |
|---|---|
| ApplInsight Server virtual machine memory | 8 GB |
| Network probe disk space | 6 GB |
| Network probe memory | 1 GB |
| Supported ESX Servers | ESX 4.1.x, or 5.0 |
| Supported vSphere versions | vSphere 4.1 or 5.0 |
| AppInsight Server TCP Port for user interface | 80, 8443 |
| Network probe TCP Port | 1194 |
The AppInsight Server virtual machine requires 50 GB of disk space, 8 GB of memory, and 4 vCPUs.
Supported servers include TC Server versions 2.5 and 2.6, Tomcat versions 6.x and 7, and JBoss versions 5.01, 5.1, and 6.
The interface supports Microsoft Internet Explorer 8 and 9, Google Chrome 12, Mozilla FireFox 3.6, and Safari 4.0.4.
